| SPECIFICATION |
|
| Model NO. |
PBL-3216E2 |
| System |
| Main Processor |
Quad Cortex A53 |
| Operating System |
Embedded LINUX |
| Video |
| Input |
16CH(12MP/8MP/6MP/5MP/4MP/3MP/1080p/1280x1024/960p/720p/D1/CIF) |
| Output |
1*HD,1*VGA |
| Audio |
| Input |
1 Port RCA, support 16CH IPC audio input |
| Output |
1 Port RCA(Linear, 1kΩ), HD output |
| Audio Bit Rate |
64kbps |
| Audio Compression standard |
G711U, G711A, AAC |
| Intercom |
support (two-way) |
| Alarm |
| Sensor Input |
4CH |
| Output |
1CH |
| Motion Detection |
16Channel, MD Zones: 396 (22 × 18) |
| Trigger Events |
Recording, Email, FTP, Snapshot, Buzzer and Screen Tips, alarm output |
| Display |
| HD Output1 |
4K(3840*2160)/2K(2560*1440)/1920*1080/1280*1024/1280*720/1024*768 |
| HD Output2 |
N/A |
| VGA |
1920*1080/1280*1024/1280*720/1024*768 |
| Display Split |
16CH/13CH/10CH/9CH/8CH/6CH/4CH/1CH |
| Digital Zoom |
YES |
| OSD |
Camera Title, Time, Recording, Motion Detection, Event Alarm |
| Recording |
| Video Compression |
H265/H264/H265+/H264+ |
| Resolution |
12MP(4000*3000),8MP(3840×2160),6MP(3072*2048),5MP(2592×1944),4MP(2688×1520/2560×1440),3MP(2048×1536),1080P(1920×1080),1280x1024,960P(1280x960),720P(1280×720),960H(960x480)D1 (720×576/720×480) |
| Record Rate |
PAL :12MP@16CHx25fps,8MP@16CHx25fps,6MP@16CHx25fps,5MP@16CH×25fps,4MP@16CHx25fps,3MP@16CH×25fps,1080P@16CH×25fps, 960P@16CH×25fps,720P@16CH×25fps, 960H@16CHx25fps,D1@16CH×25fps
NTSC: 12MP@16CHx30fps,8MP@16CHx30fps,6MP@16CHx30fps,5MP@16CH×30fps,4MP@16CHx30fps,3MP@16CH×30fps,1080P@16CH×30fps, 960P@16CH×30fps,720P@16CH×30fps, 960H@16CHx30fps,D1@16CH×30fps |
| Record Mode |
ManualTimerMotion Detection AlarmSmart Event |
| Playback & Backup |
| Local Sync Playback |
1CH 12MP@30fps,2CH 8MP@30fps,3CH 5MP@30fps, 4CH 4MP@30fps,8CH 1080P@30fps, 16CH 960P@30fps, 16CH 720P@30fps,16CH D1@30fps |
| Decode Capability |
1080P(1920x1080)@240fps |
| Remote Sync Playback |
YES |
| Search Mode |
ALL, Timing Video, Motion Detection, Alarm,Tag search,Smart Event,Pictrue,Log |
| Playback Functions |
Play, pause, fast forward, rewind, previous frame, next frame, electronic zoom, clip, audio |
| Backup Mode |
USB Device/Network |
| Network |
| Interface |
1xRJ45 10M/100/1000MAdaptive Ethernet Interface |
| Incoming Bandwidth |
160Mbps |
| Outgoing Bandwidth |
160Mbps |
| Network Functions |
IPv6,TCP/IP, HTTP,HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE |
| Onvif |
Profile S, Profile G, Profile T |
| Web Browser |
Edge,IE8-11, Google Chrome , Firefox ,Safari |
| CMS Software |
Support Windows 7/ Windows 8/Windows 10/Windows 11/MAC OS |
| Cloud Support |
Yes |
| Smart Phone |
iPhone, iPad, Android, Android Pad |
| POE |
N/A |
| WIFI |
N/A |
| Storage |
| Interface Type |
2 SATA Hard Disk Interface (3.5" SATA) |
| Capacity |
Up to 10 TB capacity for each HDD |
| eSATA |
N/A |
| General |
| Language UI |
Simplified Chinese, Traditional Chinese,English, Russian,Deutsch, French, Portuguese, Spanish, Italian, Korean, Janpanese，Ukrainian, Polski,Dutch, Greek, Czech, Arabic |
| USB Interface |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 |
| RS485 |
N/A |
| Power consumption |
DC12V/4A ≤15W (Without Hard Disk) |
| Working Environment |
-10℃～55℃, 10%～90%(humidity) |
| Dimension(W×D×H) |
380 x 316 x 51mm |
| Weight |
2.71≤ kg(without HDD) |
