Specifications
Technology Standard IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX/100Base-FX
Interface RJ45 Port 10/100Mbps 4-Port, Auto MDI/MDI-X TP/STP Cat. 3, 4, 5, 6 Cable EIA/TIA-568 100-ohm (Transmission Distance 100m) LED Indicators Per unit: Power TX Port (Link/Act, FDX/HDX, Speed), FX Port (Link/Act)
Performance Throughput 14,880pps for 10Mbps, 148,810pps for 100Mbps MAC Address 2K MAC address table
Operating Environment Temperature Operation: -40°C ~ 80°C, Storage: -45℃ ~ 85℃ Humidity 5 ~ 95% (Non-condensing) Power Consumption SFC300-SCS : 4.7W, SFC300-SCM : 5.4W, SFC300-SCS2/SCM2 : 5.2W Installation Method DIN-Rail, Panel mounting
Input Voltage DC 12 ~ 48V(Terminal Block), Polarity protection circuit
Dimension 42mm(W) x 87mm(D) x 113mm(H)
